Magnetic Track Light lighting

SL-SM04

The SL-SM04 Magnetic Track Light is a modern linear lighting solution designed for flexible indoor illumination. Available in 6W, 12W, 18W, and 24W, it features a durable die-cast aluminum body with an optical lens and a sleek black finish, making it suitable for contemporary residential and commercial interiors.

Featuring a wide 111.6° beam angle and high color rendering of CRI ≥90, the SL-SM04 provides broad, comfortable illumination with excellent color representation. It uses an SMD light source and is available in 3000K, 4000K, 6500K, 3CCT, and 4CCT options. The integrated DIP switch allows convenient color-temperature adjustment.

Designed to operate with a DC48V magnetic track power supply, the SL-SM04 offers 180° up-and-down adjustment for flexible light positioning. It features IP20 protection, an OSRAM LED chip, a rated lifetime of 50,000 hours, and a 3-year warranty, making it a reliable choice for indoor magnetic track lighting systems.

  • 6W / 12W / 18W / 24W Options
  • 111.6° Wide Beam Angle
  • CRI ≥90 High Color Rendering
  • SMD Light Source
  • OSRAM LED Chip
  • 3000K / 4000K / 6500K / 3CCT / 4CCT
  • DIP Switch Color Temperature Adjustment
  • 180° Up & Down Adjustment
  • Die-Cast Aluminum + Optical Lens
  • Black Finish
  • DC48V Magnetic Track System
  • 50,000 Hours Lifetime
  • IP20 for Indoor Use
  • 3-Year Warranty

Technical
specifications

ModelSL-SM04
Power6W / 12W / 18W / 24W
Length120mm / 250mm / 365mm / 475mm
Width34mm
MaterialDie-Cast Aluminum + Optical Lens
Body ColorBlack
Beam Angle111.6°
Light SourceSMD
LED ChipOSRAM
Luminous Efficiency50.49 lm/W
CRIRa ≥90
CCT3000K / 4000K / 6500K / 3CCT / 4CCT
Driver TypeDC48V Magnetic Track Power Supply
Power Factor≥0.5
Frequency50/60Hz
Adjustment Angle180° Up & Down
IP GradeIP20
Lifetime50,000 Hours
Warranty3 Years
